Chat Widget API

Chat window API allows you to manipulate the chat widget displayed on your website. Some common use–cases are:

  1. making the chat window pop out at the specific moment,
  2. changing the default chat bubble to custom image.

All available methods and callbacks are listed below:

Hooks

onBeforeLoad

Callback function invoked when widget code is loaded but chat window is not rendered yet. You can return false to stop the widget initialization.

window.BE_API = window.BE_API || {}; window.BE_API.onBeforeLoad = function () { // return false };

onLoad

Callback function invoked when widget code is loaded and chat window is rendered.

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = function () { // … };

onCreate

Callback function invoked after create() API method call.

window.BE_API = window.BE_API || {}; window.BE_API.onCreate = function () { // … };

onDestroy

Callback function invoked after destroy() API method call.

window.BE_API = window.BE_API || {}; window.BE_API.onDestroy = function () { // … };

onChatWindowOpen

Callback function invoked when the chat window is opened.

window.BE_API = window.BE_API || {}; window.BE_API.onChatWindowOpen = function () { // … };

onChatWindowClose

Callback function invoked when the chat window is closed.

window.BE_API = window.BE_API || {}; window.BE_API.onChatWindowClose = function () { // … };

onChatWindowHide

Callback function invoked when the chat window is hidden.

window.BE_API = window.BE_API || {}; window.BE_API.onChatWindowHide = function () { // … };

onMessage

Callback function invoked after query result.

window.BE_API = window.BE_API || {}; window.BE_API.onMessage = function (result) { console.log(result) };

onStartConversation

Callback function invoked after the conversation starts.

window.BE_API = window.BE_API || {}; window.BE_API.onStartConversation = function () { // … };

Methods

create

Create chat widget if does not exist

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = function () { window.BE_API.create(); };

destroy

Destroy chat widget if exist

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = function () { window.BE_API.destroy(); };

isInitialized

Returns true if the chat is initialized.

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = function () { window.BE_API.isInitialized(); };

resetSession

Reset current session and recreate widget.

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = function () { window.BE_API.resetSession(); };

openChatWindow

Open the chat window, should be used only inside window.BE_API.onLoad callback

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = function () { window.BE_API.openChatWindow(); };

closeChatWindow

Close the chat window, should be used only inside window.BE_API.onLoad callback

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = function () { window.BE_API.closeChatWindow(); };

hideChatWindow

Hide the chat window, should be used only inside window.BE_API.onLoad callback

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = function () { window.BE_API.hideChatWindow(); };

isChatWindowOpened

Should be used only inside window.BE_API.onLoad callback. Returns true if the chat window is open.

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = function () { window.BE_API.isChatWindowOpened(); };

isChatWindowClosed

Should be used only inside window.BE_API.onLoad callback. Returns true if the chat window is closed.

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = function () { window.BE_API.isChatWindowClosed(); };

isChatWindowHidden

Should be used only inside window.BE_API.onLoad callback. Returns true if the chat window is hidden.

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = function () { window.BE_API.isChatWindowHidden(); };

setUserAttributes

Set user attributes. Read more about user attributes here:

https://www.chatbot.com/docs/users#update-user

Payload
parameter type description
Object Object( Entry Object(1, 99) ) required Object with entries
Entry Object
parameter type description
key String(1, 128) Attribute name
value String(1, 1024) Attribute value

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = () => { window.BE_API.setUserAttributes({ email: ‘support@botengine.ai’, name: ‘Botengine Support’ }) }

setSessionAttributes

Set your custom attributes that will be sent to the query. Each method call will overwrite existing parameters. Read more about attributes here: https://www.chatbot.com/docs/chat#parameters

Payload
parameter type description
Object Object( Entry Object(1, 99) ) required Object with entries
Entry Object
parameter type description
key String(1, 128) Attribute name
value String(1, 1024) Attribute value

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = () => { window.BE_API.setSessionAttributes({ email: ‘support@botengine.ai’, name: ‘Botengine Support’ }) }

sendMessage

Send a message as visitor.

Payload
parameter type description
payload.message String(1, 256) required Message
payload.postback String(1, 256) Postback

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = () => { window.BE_API.sendMessage({ message: ‘message’, postback: ‘postback’ }) }

sendTrigger

Trigger the specific interaction.

Payload
parameter type description
payload String(1, 50) required Trigger name

window.BE_API = window.BE_API || {}; window.BE_API.onLoad = () => { window.BE_API.sendTrigger(‘custom_trigger’) }

Examples

Custom Chat Button

Change the default chat bubble (circle) to your own button with the use of this example. The code is available here. Custom Chat Button
